Use this 1/2-in Poly Elbow Fitting to run 1/2-in Poly Tubing (MLT-25), (MLT-71), (MLT-72), or 1/2-in In-Line Drip Tubing (MLD-HDT100) in and around tight corners.
Typically used where the 1/2-in Poly Tubing needs to run in a 90° shape around corners of the landscape or garden.
To attach the 1/2-in Poly Tubing, first push the collar back to expose the barb with a built-in O-ring.
Push and wiggle the 1/2-in Poly Tubing onto the fitting and under the collar until snug.
While holding the tubing with 1 hand, turn the ears of the collar in a left counterclockwise motion to tighten and lock onto the 1/2-in Poly Tubing
Repeat these steps for both sides of this Elbow Fitting.
This fitting can be uninstalled easily by unthreading the collar in a clockwise motion then by pulling off the 1/2-in Poly Tubing.
If you find it difficult to get the 1/2-in Poly Tubing onto the fitting, use a little olive oil or vegetable oil by wiping it on the inside of the wall of 1/2-in Poly, then push in the fittings.
(1 Elbow per bag)
(Made in the USA)
