Timer has a 3/4- in female swivel hose thread inlet with a 3/4-in male hose thread outlet
Has a large display screen to view all settings at once which includes a current time and start water time that can be set to the nearest minute
Has a setting for the amount of time to water with a choice of watering for 1 minute up to 6 hours at a time with an option to water up to 4 times a day
Separate scheduling for two different areas
Automatic or manual settings
Timer has a battery strength indicator that will show an indication if the battery is "ok" or "low" and requires two 1.5 Volt AA alkaline batteries not included and sold separately
This timer will help to make watering your plants easier by automatically turning the water on and off and comes with a 7-year limited warranty
RECOMMENDATIONS & LIMITATIONS
When installing any irrigation system, it is important to be aware of manufacturer recommendations and potential system limitations. Please be aware of the following:
Designed for outside use only
The timer (MLWT-1ZONE, MLWT-TWOZONE or MLWT-EGG) must always be the first thing attached to the faucet, then the pressure regulator (MLA-58 or MLD-25PR), filter (MLFF-41), and then the vinyl faucet adapter: either the (MLF-33) for the 1/2-in poly or the 1/2-in in-line dripper tubing, or the (MLA-FAS) for the 1/4-in vinyl or the 1/4-in in-line dripper tubing
When winterizing your system, before the first frost completely remove the timer and batteries and store inside
Rechargeable batteries are not recommended
For technical support call 863-439-3200 or email sales@misterlandscaper.com
Minimum operating pressure for Timer: 20 PSI
Maximum operating pressure for Timer: 80 PSI
Timer manufactured in Taiwan
Valve Reset Steps for Timer:
- Turn off the water at the spigot or faucet.
- Set the timer to "Off" by moving the arrow to the Off position.
- Press the On/Off Manual button, then hit the + (plus) button and set it for 1 minute.
- You'll see a watering faucet animation. Wait for the full minute to finish.
- Turn the spigot/faucet back on slowly.
- Press the On/Off Manual button again and set it for 1 minute to check if the water is now coming from the timer.
- After 1 minute, you should hear the click of the valve closing and the water turning off.
If it still doesn’t work:
- Try one more time repeating Steps 1 -7.
- Also, make sure your water pressure is between 20-80 PSI.
-
- If none of this works and your water pressure is between 20 – 80 PSI, Please email us at sales@misterlandscaper.com so we can assist you.
